Pentagon Semi Universal Dividing Head-Indexing Head Set BS0 5"

Pentagon Semi Universal Dividing Head-Indexing Head Set BS0 5" Specification

Product Type
Pentagon Semi Universal Dividing Head-Indexing Head Set BS1

Material
Stainless Steel

Computerized
Yes

Automatic
Yes

Color
Silver

Warranty
1 Year

Pentagon Semi Universal Dividing Head-Indexing Head Set BS0 5" Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About Pentagon Semi Universal Dividing Head-Indexing Head Set BS0 5"

Features

1. This dividing head set includes headstock, 5" 3-jaw lathe chuck, tailstock, center&driving dog, threaded back plate & 3 dividing plates. 1:40 ratio.

2. Headstock adjustable from 10 downward to 90 degree upward from the horizontal position

3. By using a dividing scale ring, vernier, locating pin, index plate and change gear, workpieces placed can be divided into equal partitions according to your demand

4. The 24 quick-dividing holes can complete 2, 3, 4, 6, 8, 12, 24 division indexing

5. 3 dividing plates are attached along with the dividing head for indirect dividing in any division indexing 2-50, 51-380 except prime numbers and certain other numbers

Technical Specification

1. Model	BS0
2. Taper of center	MT-2
3. Spindle Through Hole	18 mm
4. Suitable chucks	125 mm
5. Weight (Kg)-Approx.	30 Kg
6. Center Height	100 mm
7. Dimensions :	410 x 235 x 205mm

Std Accessories Supplied with

1. Pentagon Dividing Head Set model BS0 with 5" Chuck, Tailstock, Dividing Plates, and other std accessories

2. Dividing Plates

3. Tailstock

4. 3 Jaw Chuck 125mm

5. Operation Manual

Versatile Precision Engineering

Engineered for reliability and versatility, the Pentagon Semi Universal Dividing Head-Indexing Head Set BS0 5" delivers consistent results for skilled machinists. Its semi universal design accommodates an array of machining tasks, ensuring precise angular cuts and indexing.

Advanced Features for Efficiency

Equipped with computerized and automatic capabilities, this dividing head reduces manual intervention and increases productivity. Operators benefit from seamless setup and smooth transitions between tasks, making it ideal for advanced manufacturing environments.

Quality Materials and Dependability

Manufactured from corrosion-resistant stainless steel, the BS0 5" guarantees longevity and performance. The product comes with a one-year warranty, reinforcing its reliability for industrial and commercial users in India.

FAQs of Pentagon Semi Universal Dividing Head-Indexing Head Set BS0 5":

Q: How does the Pentagon BS0 5" Dividing Head improve precision in machining?

A: The Pentagon BS0 5" Dividing Head employs computerized and automatic indexing, enabling highly accurate angular positioning for milling, drilling, and gear-cutting operations. Its robust design ensures consistent precision across repetitive processes.

Q: What are the key benefits of using a computerized and automatic dividing head like the BS0 5"?

A: Computerized and automatic operations reduce human error, streamline workflows, and enhance accuracy. This leads to higher productivity and repeatable results, especially in complex or repetitive machining tasks.

Q: When should I use the BS0 5" Indexing Head in my manufacturing process?

A: The BS0 5" should be employed whenever precise indexing or angular cuts are required, such as in the production of gears, splines, and fluted shafts, or any operation demanding meticulous control over rotational positioning.

Q: Where can I purchase the Pentagon Semi Universal Dividing Head-Indexing Head Set BS0 5" in India?

A: This product is available across India through authorized distributors, importers, manufacturers, producers, suppliers, traders, and wholesalers. You can inquire with industrial equipment suppliers for stock and quotation details.

Q: What is the process for setting up and operating the BS0 5" Dividing Head?

A: To set up, securely attach the dividing head to your machines worktable, calibrate using the computerized panel, and select the automatic settings suited for your operation. The device offers easy integration with standard machining tools.

Q: How does the stainless steel build benefit industrial users?

A: Stainless steel provides excellent durability, resistance to corrosion, and long-term stability. This ensures consistent performance of the BS0 5" in demanding industrial conditions, reducing maintenance needs and downtime.
