knee type milling machine

knee type milling machine Specification

Drive
Gear Drive

Motor Power
2 HP

Noise Level
< 75 dB

Operating Temperature
0C to 45C

Features
Heavy duty design, high rigidity, precision guides

Voltage
415V

Accuracy
0.02 mm

Production Capacity
One piece per cycle

Model No
KM-1000

Cooling System
Integrated coolant tank & pump

Frame Type
Cast Iron Body

Control System
Manual and mechanical feed

Frequency
50 Hz

Power Rating
2 HP / 1.5 kW

Machine Type
Vertical Knee Type Milling

Lubricating System
Centralized hand pump lubrication

Product Type
Knee Type Milling Machine

Technology
Conventional Milling

Power Source
Electric

Operating Type
Semi-Automatic

Power
2 HP

Surface Treatment
Painted and Anti-Rust

Dimension (L*W*H)
1600 x 1700 x 1900 mm

Weight (kg)
Approx 1000 kg

Color
Green

Usage & Applications
Metal cutting, slotting, drilling, tapping

Spindle Speed Range
60-1600 rpm

Main Spindle Motor
2 HP, 3 Phase

Spindle Taper
ISO 40

Coolant Capacity
40 liters

Table Travel (X/Y/Z)
600 mm / 250 mm / 400 mm

Rapid Traverse Rate
1100 mm/min

Number of T-Slots
3 Slots

Feed Range
Manual & Auto variable

Table Size
900 x 300 mm

Slot Size
14 mm

Main Construction Material
High grade cast iron

Max Distance Spindle to Table
460 mm

Electrical Protection
Included

Safety Features
Emergency stop, overload protection, interlocking

About knee type milling machine

Features Included

1. Rectangular table guide ways with high stability

2. Hardened and ground table surface

3. Automatic feeds on 3 Axes

4. Swivel angle and vertical milling head +45 degree or -45 degree

5. Rapid speed of table

Std Accessories Included

1. Vertical milling head

2. Mill chuck

3. 7:24 Middle-sleeve

4. Wrench S22-24

5. Inner-hexagonal spanners

6. Machine Vice 6"

7. Horizontal milling arbor, Dia. 40

8. Horizontal draw bar

9. Vertical draw bar

10.Hexagon nut

11.Operational manual

12.Quality certificate

Opt Accessories (Extra)

1. 3 Axis DRO with suitable linear scales and fittings (Rs 34000)

2. Semi universal dividing head with 6" chuck and tail stock(Rs 46300)

3. H-V rotary table 10" dia with indexing plates(Rs 25000)

4. 2 Axis DRO with suitable linear scales and fittings (Rs 23000)

Tech Details :

Spindle Taper : ISO50

Distance spindle to table surface : 0-400 mm

Distance between spindle center to vertical guide way : 175 mm

Spindle speed/Steps : 30-1500 rpm/12 steps

Table size : 1500 x360 mm

Table travel Longitudinal : 950 mm

Table Travel Cross : 320 mm

Table Travel Up and down : 400 mm

Worktable Vertical, Cross mobile : 22555 mm/min

8 level Feed speed (Max speed (Rapid)) : 810 mm/min

Worktable Slots Number : 3

Worktable Slots Width : 18 mm

Worktable Slots Distance : 80 mm

Motor : 4 kW

Worktable mobile feed motor : 750 W

Cooling pump motor : 90 W

Overall dimensions : 1900x1720x1750

Weight (N.W/G.W) : 2400 / 2500 kg.

Heavy-Duty Construction for High Precision

Built from high-grade cast iron and engineered for rigidity, the KM-1000 offers excellent stability and durability for continuous industrial use. Its heavy-duty frame and precision guides minimize vibration, enhancing the precision of your milling operations.

Operator-Centric Safety Features

The machine prioritizes operational safety with features like emergency stop, overload protection, and interlocking. These systems ensure a secure environment, reducing risks during metal cutting, slotting, and other procedures.

Flexible Table and Spindle System

A generous 900 x 300 mm table with a substantial travel range (X/Y/Z: 600/250/400 mm) lets you handle diverse jobs. The ISO 40 spindle, 601600 rpm speed range, and both manual and auto feed give the operator flexibility for different cutting conditions and materials.

FAQs of knee type milling machine:

Q: How does the knee type milling machine ensure high accuracy during operations?

A: This milling machine is manufactured with high rigidity and precision guides, constructed from cast iron to reduce vibrations. With an accuracy of 0.02 mm, fine adjustment mechanisms, and centralized hand pump lubrication, it ensures consistent precision throughout your machining tasks.

Q: What are the safety features available on this milling machine?

A: Safety is prioritized with an emergency stop button, overload protection system, and mechanical interlocking. These features help protect users and the machine from unexpected failures or mishandling during operation.

Q: When should the machines integrated coolant system be used?

A: The integrated coolant system, featuring a 40-liter tank and pump, should be used during prolonged or high-temperature machining sessions to effectively dissipate heat, cool the cutting tool, and extend both tool life and machining accuracy.

Q: Where can this vertical knee type milling machine be effectively utilized?

A: This model is ideal for manufacturing units, tool rooms, metal workshops, and educational institutes across India where precision metal cutting, slotting, drilling, or tapping operations are required.

Q: What benefits does the semi-automatic operation and gear drive offer?

A: Semi-automatic operation simplifies repetitive machining tasks, increasing productivity and consistency. The reliable gear drive ensures stable transmission of power, enabling efficient material removal even under variable speeds and feeds.

Q: How should the tables T-slots and travel capacities be utilized?

A: Utilize the three 14 mm T-slots to securely clamp a range of workpieces or fixtures. The spacious 900 x 300 mm table with X/Y/Z travel (600/250/400 mm) accommodates large and complex metal components for increased versatility in operations.
