        PENTAGON High Precision Vertical Horizontal Rotary Table Model HV10

        PENTAGON High Precision Vertical Horizontal Rotary Table Model HV10
        PENTAGON High Precision Vertical Horizontal Rotary Table Model HV10

        PENTAGON High Precision Vertical Horizontal Rotary Table Model HV10 Specification

        • Product Type
        • Pentagon High Precision Vertical Horizontal Rotary Table HV
        • Material
        • Stainless Steel
        • Computerized
        • No
        • Automatic
        • No
        • Color
        • Silver
        • Warranty
        • 1 Year


        PENTAGON High Precision Vertical Horizontal Rotary Table Model HV10 Trade Information

        • Minimum Order Quantity
        • 1 Piece
        • Supply Ability
        • 1000 Pieces Per Month
        • Delivery Time
        • 7 Days
        • Main Domestic Market
        • All India


        About PENTAGON High Precision Vertical Horizontal Rotary Table Model HV10

        1. This Rotary Table has been designed to be used where a precision work positioning device is required. It allows the operator to mill or drill components at exact intervals around a fixed axis.
        2. This Rotary Table can be used in both the horizontal or vertical plane.

        1. Size 10 Inch (250mm)
        2. Table Our Dia. (A1) 106
        3. Table Our Dia.(D) 254
        4. Table - Height (H) 109
        5. Base Dimensions -(H1) 163
        6. Base Dimensions -(A) 321
        7. Base Dimensions -(B) 276
        8. Width of T Slot (e) 14
        9. Bolt Slot 17
        10. Horizontal Load Capacity 90 Kg
        11. Vertical Load Capacity 50 Kg
        12. Center Sleeve MT-3
        13. Gross Weight (Kg) Approx. 45 Kg
        PENTAGON High Precision Vertical Horizontal Rotary Table Model HV10
